3.5KW Stainless Steel Filling Capping Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | HUITUO |
| Certification: | CE,ISO |
| Model Number: | CRP-8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden case |
| Delivery Time: | 15-60 days |
| Payment Terms: | TT/LC |
| Supply Ability: | 30set/month |
|
Detail Information |
|||
| Packaging Type: | Can& Bottle | Packaging Material: | Glass, Plastic, Wood |
|---|---|---|---|
| Type: | Capping Machine | Condition: | New |
| Application: | Beverage, Chemical, Commodity, Food, Medical | Driven Type: | Mechanical |
| Automatic Grade: | Automatic | Voltage: | AC 220V, 50Hz |
| Power: | 3.5 Kw | Dimension(L*W*H): | 2000mm*1100mm*2200mm |
| Weight: | 800KG | Material: | SS316L |
| Parts: | Famous Brand | Capping Head: | 8 |
| Speed: | ≤6000 Bph | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Port: | Shanghai | ||
| High Light: | 3.5kw filling and capping machine,ss316l bottle filling and capping machine,6000 bph filler capper machine |
||
Product Description
Best trading products CRP-8 Full automatic cap chuck machine China supplier sales
CRP-8 Full automatic chuck capping machine
Major Characteristics:
This capping machine is delicate designed for sealing plastic interior and exterior caps of cylinder bottles.
Especially for caps similar with edible bottles’. not only the capping speed is fast, but also high qualified
rate of capping, reduces labor and increases productivity. This capper also suits recycle bottles well.
This machine is reliable, simple operation, reasonable design, high automation. Cap sorting and cap loading,
can be done automatically as well with the ejector for ejecting incorrect caps.
Technical parameter:
|
No. |
Items |
Performance |
|
01 |
Number of capping heads |
8 |
|
02 |
Production capacity |
≤6000 bottles/hour |
|
03 |
container diameter |
Φ50mm-Φ100mm |
|
04 |
container height |
80mm~280mm |
|
05 |
cap diameter |
Φ17mm~Φ35mm |
|
06 |
Inner plug diameter |
Φ12mm~Φ35mm |
|
07 |
Power supply |
AC220V ; 50Hz |
|
08 |
Power |
3.5 Kw |
|
09 |
Machine dimension(L×W×H) |
2000mm×1100mm×2200mm |
|
10 |
Machine weight |
800Kg |
|
11 |
Vacuum source |
6.67×10-2 Pa ,air exhausted 15 L/S |
Packaging & Shipping:
After-sales Service:
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets,
(4) We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
About Us:
-- Focusing on Development, Packaging Industry Leader
-- Keeping on Recruiting Talents and Innovation
-- Advanced equipment, Guaranteed quality
FAQs
1. What types of packaging machines does Huituo offer?
We offer complete packaging systems that include one or more of the following machines: bottle unscrambler, filling machine, capping machine, cap unscrambler, bottle rinsers and washers, sleeve labelers, inkjet printers for labelers, conveyors, turntables, and monoblock.
2. What are the basic types of capping machines?
We have three series of capping machine:
1. SPU
Permanent magnet clutch
Suitable for the bottles with similar heights
Can be customized based on requirements
Max. Speed: 100bpm
2. SPI:
Permanent magnet clutch
Suitable for more bottles and caps
Can be customized based on requirements
Max. Speed: 200bpm
3. SPM:
Servo control
Suitable for more bottles and caps
Higher torque accuracy
Easier operation
Can be customized based on requirements
Max. Speed: 200bpm
3. What's the difference between semi-automatic and automatic capping machine?
Semi-automatic capping machines require one or more operators to place caps onto the cap-sending channels. The automatic capping machine will be equipped with cap elevator and unscrambler, achieving the highest production rates. It is suitable for round cap and pump.
4. What are the basic types of filling machines?
Usually we have three types of filling machines
1. self-flow filling machine
2. Piston filling machine (Option 1: one servo motor to control all filling nozzles; Option 2: each filling head is controlled by each motor)
3. Flowmeter filling machine (Option 1: electromagnetic flowmeter; Option 2: mass flow meter)
4. Pneumatic filling machine
Now, we have the forth filling machine for the hand sanitizer with 70%-80% alcohol, as it is much safer than the above three.
5. Should I choose linear filling machine or rotary filling machine?
Usually, if the speed is over 6,000bph(based on 500ml), we will suggest customer choose the rotary filling machine. The linear one is more suitable for lower speed.
6. Do installation and training included in the machinery cost?
Training is included with most Huituo machinery but installation and commissioning at site requires an additional fee.
7. What warranties does Huituo offer?
One year on non-wear parts and labor. Huituo warranties can also be extended, ask a salesperson for information.
8. Can I rent equipment from Huituo?
Yes. Ask a salesperson for more information.
9. How long will the machine be delivered?
It depends on the degree of customization. The higher degree, the longer delivery time.
